Ducati MONSTER S2R 1000 User Manual

48
E
Changing the air filter (fig. 40)
The air filter must be renewed at the intervals indicated in the
periodic maintenance table shown in the Warranty Booklet.
To access the airbox, lift the fuel tank as described in
(page 47).
To remove the filter, release the clips (1) on both sides of
the airbox cover and remove the cover (2, fig. 40).
Remove the old filter cartridge (3, fig. 41) and fit a new one.
Important
A dirty filter reduces the amount of intake air, which
increases fuel consumption, reduces engine power and
causes deposits to form on the spark plugs.
Do not use the motorcycle without a filter; as impurities in
the air could get into the engine and cause damage.
Reinstall the filter correctly in its housing in the airbox, as
shown in the figure, and refit all the parts originally removed.
Important
If using the machine on wet or dusty roads, the air
filter cartridges should be renewed more frequently than
the intervals in the periodic maintenance table in the
Warranty Booklet.
1
2
fig. 40
3
fig. 41

Ducati MONSTER S2R 1000 Specifications

General

Displacement	992 cc
Bore x Stroke	94 mm x 71.5 mm
Compression Ratio	10:1
Power	95 hp (69.9 kW) @ 8000 rpm
Fuel System	Electronic fuel injection, 45 mm throttle body
Exhaust	2-1-2 system with catalytic converter and lambda probe
Cooling	Air cooled
Transmission	6-speed
Frame	Tubular steel trellis frame
Front Brake	2 x 320 mm discs, 4-piston calipers
Rear Brake	245 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Seat Height	800mm (31.5 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Final Drive	Chain
Front Suspension	Showa 43mm upside-down fork
Rear Suspension	Progressive with preload and rebound Sachs adjustable monoshock
Fuel Capacity	14 liters (3.7 gallons)
