27
E
Main components and devices
Position on motorcycle (fig. 18)
1) Fuel tank filler cap.
2) Seat lock.
3) Helmet cable pin.
4) Passenger grabhandle.
5) Sidestand.
6) Rearview mirrors.
7) Rear shock absorber adjusters.
8) Front fork adjuster.
9) Tank support strut.
10) Seat cover
11) Fuel tank release lever.
12) Headlight fairing.
13) Catalytic converter.
6
10
4
1
9
12
13
11
7
2
3
8
fig. 18
