Ducati MONSTER S2R 1000 User Manual

56
E
Replacing bulbs
Before replacing a burnt-out bulb, make sure that the new
one complies with voltage and wattage as specified in
the “Electrical System” paragraph on page 78.
Headlight
(fig. 48 - fig. 49 - fig. 50 - fig. 51)
To carry out maintenance on the headlight, it is advisable to
remove the headlight fairing as described in the paragraph
“Removing the headlight shell” on page 46.
To access the headlight bulbs, loosen the lower screw (1)
that attaches the lens/reflector assembly to the shell.
Disconnect the wiring connector (2, fig. 49) from the
headlight bulb. Release the bulb retaining clip (3, fig. 49)
and remove the bulb from its housing.
1
fig. 48
3
2
fig. 49

Ducati MONSTER S2R 1000 Specifications

General

Displacement	992 cc
Bore x Stroke	94 mm x 71.5 mm
Compression Ratio	10:1
Power	95 hp (69.9 kW) @ 8000 rpm
Fuel System	Electronic fuel injection, 45 mm throttle body
Exhaust	2-1-2 system with catalytic converter and lambda probe
Cooling	Air cooled
Transmission	6-speed
Frame	Tubular steel trellis frame
Front Brake	2 x 320 mm discs, 4-piston calipers
Rear Brake	245 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Seat Height	800mm (31.5 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Final Drive	Chain
Front Suspension	Showa 43mm upside-down fork
Rear Suspension	Progressive with preload and rebound Sachs adjustable monoshock
Fuel Capacity	14 liters (3.7 gallons)
