Ducati MONSTER S2R 1000 User Manual

30
E
Sidestand (fig. 22)
Important
Before lowering the sidestand, check that the ground
is sufficiently even and hard.
Do not park on soft or pebbled ground or on asphalt melted
by the sun etc. or the motorcycle may fall over.
When parking on a slope, always park with the rear wheel
on the downhill side.
To lower the sidestand, hold the motorcycle handlebars
with both hands and push down on the stand (1) with your
foot until it is fully extended. Tilt the motorcycle until the
sidestand is resting on the ground.
Warning
Do not sit on the motorcycle when it is supported on
the sidestand.
To raise the sidestand to the rest position (horizontal position),
tilt the motorcycle to the right and, at the same time, lift the
stand (1) with your foot.
Notes
It is advisable to check periodically that the stand
mechanism (consisting of two springs, one inside the other)
and safety sensor (2) are working properly.
Notes
The engine can be started with the sidestand down
and the gearbox in neutral. If starting with a gear engaged,
pull in the clutch lever (in this case the sidestand must be up).
1
2
fig. 22

Ducati MONSTER S2R 1000 Specifications

General

Displacement	992 cc
Bore x Stroke	94 mm x 71.5 mm
Compression Ratio	10:1
Power	95 hp (69.9 kW) @ 8000 rpm
Fuel System	Electronic fuel injection, 45 mm throttle body
Exhaust	2-1-2 system with catalytic converter and lambda probe
Cooling	Air cooled
Transmission	6-speed
Frame	Tubular steel trellis frame
Front Brake	2 x 320 mm discs, 4-piston calipers
Rear Brake	245 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Seat Height	800mm (31.5 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Final Drive	Chain
Front Suspension	Showa 43mm upside-down fork
Rear Suspension	Progressive with preload and rebound Sachs adjustable monoshock
Fuel Capacity	14 liters (3.7 gallons)
