Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0 85
Table 16. Technical Specifications (Continued)
Input Rated Frequency
50/60-Hz selectable, auto configuring
Output Voltage Regulation
±1% static, Phase to Neutral
±2% static, Phase to Phase
±5% dynamic at 100% resistive load change
Response time <1 ms
Output Voltage Distortion
<2% THD linear load
<5% THD non-linear load
Output Frequency
50/60-Hz selectable or auto configuring
Output Frequency Regulation
Synchronization to line
Output Frequency Conversion
Frequency/phase-converter operation with derated output load capacity to
80%; Frequency Conversion mode can be configured through the front panel or through XCP
commands.
Bypass is not available in Frequency Conversion mode.
Output Overload
101–110% for 10 minutes
111–125% for 60 seconds
126–149% for 5 seconds
>150% for 300 milliseconds
Table 17. Model Specifications
15 kVA Model
Output Voltage (Line Line)
200 220 240 208 220
Output Voltage (Line Neutral)
100 110 120 120 127
Input Current*
71A
71A 71A
71A 67A
Output Current 63A 63A 63A 63A 59A
Output kVA (Line–Line Loads)
12.5 13.8 15.0 13.0 13.0
Output kVA (Line–Neutral Loads)
12.5 13.8 15.0 15.0 15.0
Output kW
11.3 12.4 13.5 13.5 13.5
Output Peak Current
155 155 155 155 155
Efficiency (Minimum)
88% 88% 88% 88% 88%
Power Dissipation (BTU/hr)
5582 5582 5582 5582 5582
DC Voltage (Supply)
192 192 192 192 192
12 kVA Model
Output Voltage (Line Line)
200 220 240 208 220
Output Voltage (Line Neutral)
100 110 120 120 127
Input Current*
68A 62A 57A 57A 54A
Output Current
60A 55A 50A 50A 47A
