Eaton 9355 UPS (20/30kVA) Installation and Operation Manual 164201626—Rev F www.eaton.com/powerquality 79
Chapter 11 UPS Maintenance
This section explains how to:
l
Care for the UPS and batteries
l
Recycle used batteries or UPS
l
Use the maintenance bypass switch (MBS)
l
Use parallel bypass
UPS and Battery Care
For the best preventive maintenance, keep the area around the UPS clean and dust–free. If the atmosphere is
very dusty, clean the outside of the system with a vacuum cleaner.
For full battery life, keep the UPS at an ambient temperature of 77°F (25°C).
Note: The batteries in the UPS are rated for a 3–5 year service life. The length of service life varies,
depending on the frequency of usage and ambient temperature. Batteries used beyond expected
service life will often have severely reduced runtimes. Replace batteries at least every 5 years to keep
units running at peak efficiency.
Storing the UPS and Batteries
When storing the UPS and optional cabinets, the following requirements should be met:
l
Verify that the battery circuit breaker is in the OFF position.
l
Avoid temperature and humidity extremes. To maximize battery life, the recommended storage temperature
is 59°F (15°C) to 77°F (25°C).
l
If you store the UPS for a long period, recharge the batteries every 10 months by applying utility power. The
batteries charge to 80% capacity in approximately 3 hours. However, it is recommended that the batteries
charge for 48 hours after long-term storage.
l
Check the battery recharge date on the shipping carton label. If the date has expired and the batteries were
never recharged, do not use the UPS. Contact your service representative.
When to Replace Batteries
When the indicator flashes and the LCD panel displays Battery Failure, the batteries may need replacing.
Contact your service representative to order new batteries.
Change the batteries approximately every five years.
Recycling the Used Battery or UPS
Contact your local recycling or hazardous waste center for information on proper disposal of the used battery
or UPS.

Eaton 9355 Specifications

General

Efficiency	91 %
Noise level	58 dB
Output power	27000 W
Input frequency	50/60 Hz
Audible alarm(s)	Yes
Input power factor	0.99
Output power factor	0.9
Output power capacity	30 kVA
Input operation voltage (min)	220 V
Input current Total Harmonic Distortion (THD)	5 %
RS-232 ports	1
AC outlet types	-
AC outlets quantity	- AC outlet(s)
Safety	IEC 62040-1-1, IEC 60950, EN 62040-1-1, UL 1778, NOM-0190SCP8-1993
Form factor	Tower
Display type	LCD
Certification	EN 50091-2 Class A\\r UL, cUL, NOM-NYCE
Product color	Black
Battery technology	Sealed Lead Acid (VRLA)
Typical backup time at half load	- min
Operating altitude	0 - 3000 m
Storage temperature (T-T)	0 - 25 °C
Operating temperature (T-T)	10 - 40 °C

Weight and Dimensions

Depth	866.14 mm
Width	508 mm
Height	1676.4 mm
