Eaton 9355 UPS (20/30kVA) Installation and Operation Manual 164201626—Rev F www.eaton.com/powerquality 83
Chapter 12 Specifications
This section provides the following specifications:
l
Model list
l
Dimensions and weights
l
Environmental and safety specifications
l
Technical specifications
l
Model specifications
l
Battery specifications
l
Battery runtimes
Table 8. Model List
UPS Description Power Rating
PW9355-20 UPS with internal batteries 20 kVA, 18 kW
PW9355-30 UPS with internal batteries 30 kVA, 27 kW
Extended Battery Cabinet (EBC) Description
EBC 36 EBC with 2 strings
EBC 72 EBC with 4 strings
Table 9. Dimensions and Weights
Eaton 9355 Cabinet
Dimensions (H W D)
Including Conduit Landing Box
Weight
UPS 66.3” x 19.4” x 34.1” (168 x 49 x 87 cm) 1160 lb (526 kg)
EBC 36 66.3” x 19.4” x 34.1” (168 x 49 x 76 cm) 1160 lb (526 kg)
EBC 72 66.3” x 19.4” x 34.1” (168 x 49 x 76 cm) 2060 lb (934 kg)
Options Cabinet with Single (Input or Output) Transformer 66.3” x 19.4” x 34.1” (168 x 49 x 87 cm) 535 lb (243 kg)
Options Cabinet with Dual (Input and Output) Transformer 66.3” x 19.4” x 34.1” (168 x 49 x 87 cm) 792 lb (360 kg)
Options Cabinet with Maintenance Bypass Switch (MBS) Only 66.3” x 19.4” x 34.1” (168 x 49 x 87 cm) 205 lb (93 kg)
Table 10. Environmental and Safety Specifications
Operating Temperature 50°F to 104°F (10°C to 40°C)
Optimal battery performance: 77°F (25°C)
Transit Temperature -13°F to 131°F (-25°C to 55°C)
Storage Temperature 32°F to 77°F (0°C to 25°C)
Recommended battery storage: 59°F to 77°F (15°C to 25°C)
Ventilation Front air intake, forced air, six fans, positive pressurization, temperature UPS-monitored
Altitude 9,843 ft (3,000m) operating without derating 32,810 ft (10,000m) during transportation
Relative Humidity 5–95% noncondensing
Audible Noise <62 dBA
Surge Suppression ANSI C62.41 Category B3
Safety Conformance NOM-019-SCFI, UL 1778, CSA C22.2, No. 107.3
Agency Markings cULus
EMC (Class A) IEC 62040-2, FCC Part 15, ICES-003

Eaton 9355 Specifications

General

Efficiency	91 %
Noise level	58 dB
Output power	27000 W
Input frequency	50/60 Hz
Audible alarm(s)	Yes
Input power factor	0.99
Output power factor	0.9
Output power capacity	30 kVA
Input operation voltage (min)	220 V
Input current Total Harmonic Distortion (THD)	5 %
RS-232 ports	1
AC outlet types	-
AC outlets quantity	- AC outlet(s)
Safety	IEC 62040-1-1, IEC 60950, EN 62040-1-1, UL 1778, NOM-0190SCP8-1993
Form factor	Tower
Display type	LCD
Certification	EN 50091-2 Class A\\r UL, cUL, NOM-NYCE
Product color	Black
Battery technology	Sealed Lead Acid (VRLA)
Typical backup time at half load	- min
Operating altitude	0 - 3000 m
Storage temperature (T-T)	0 - 25 °C
Operating temperature (T-T)	10 - 40 °C

Weight and Dimensions

Depth	866.14 mm
Width	508 mm
Height	1676.4 mm
