Eaton 9355 UPS (20/30kVA) Installation and Operation Manual 164201626—Rev F www.eaton.com/powerquality 87
Chapter 13 Troubleshooting
The Eaton 9355 is designed for durable, automatic operation and also alerts you whenever potential operating
problems may occur. Usually the alarms shown by the control panel do not mean that the output power is
affected. Instead, they are preventive alarms intended to alert the user. Use the following troubleshooting chart
to determine the UPS alarm condition.
Typical Alarms and Conditions
The following table describes typical alarms and conditions; check the Event Log through the control panel for
a list of active alarms. If an alarm appears with a service code, please contact the Help Desk (see page 88).
Alarm or Condition Possible Cause Action
On Battery
LED is on.
1beep every second.
A utility failure has occurred and the UPS is in Battery
mode.
The UPS is powering the equipment with battery power. Prepare your
equipment for shutdown.
Battery Low
LED is on.
Continuous beep for
10 seconds.
The battery is running low. Five minutes or less of battery power remains (depending on load
configuration and battery charge). Save your work and turn off your
equipment.
When utility power is restored, the UPS restarts automatically, provides
power to the load, and charges the battery.
Battery Breaker
LED is on.
1 beep every second.
The UPS does not recognize the internal batteries. Verify the battery circuit breaker is in the ON position. If the condition
persists, contact your service representative.
Overload
LED is on.
1 beep every second.
The power requirements exceed the UPS capacity
(greater than 100% of nominal; see page 84 for
specific output overload ranges).
Remove some of the equipment from the UPS. The UPS continues to
operate, but may switch to Bypass mode if the load increases. The alarm
resets when the condition becomes inactive.
Overtemperature
LED is on.
1 beep every second.
The UPS internal temperature is too high or the fan has
failed.
Turn the maintenance bypass switch to the SERVICE position. Otherwise,
shut down the UPS.
Clear vents and remove any heat sources. Allow the UPS to cool. Ensure
the airflow around the UPS is not restricted.
If the alarm disappears, turn the maintenance bypass switch back to the
UPS position.
If the condition persists, contact your service representative.
Battery test failed The batteries need service. Contact your service representative.
The UPS does not start. The main utility breaker is off. Verify that the main utility breaker is on.
The input circuit breaker is off. Verify that the UPS input circuit breaker is on.
The remote emergency power-off (REPO) switch is
active or the REPO connector is missing.
Reset the REPO switch and restart the UPS. Verify that the REPO
connector is present.

Eaton 9355 Specifications

General

Efficiency	91 %
Noise level	58 dB
Output power	27000 W
Input frequency	50/60 Hz
Audible alarm(s)	Yes
Input power factor	0.99
Output power factor	0.9
Output power capacity	30 kVA
Input operation voltage (min)	220 V
Input current Total Harmonic Distortion (THD)	5 %
RS-232 ports	1
AC outlet types	-
AC outlets quantity	- AC outlet(s)
Safety	IEC 62040-1-1, IEC 60950, EN 62040-1-1, UL 1778, NOM-0190SCP8-1993
Form factor	Tower
Display type	LCD
Certification	EN 50091-2 Class A\\r UL, cUL, NOM-NYCE
Product color	Black
Battery technology	Sealed Lead Acid (VRLA)
Typical backup time at half load	- min
Operating altitude	0 - 3000 m
Storage temperature (T-T)	0 - 25 °C
Operating temperature (T-T)	10 - 40 °C

Weight and Dimensions

Depth	866.14 mm
Width	508 mm
Height	1676.4 mm
