ECS KV2 Extreme User Manual

3-16
3.3-6 PNP/PCI Configurations
These options configure how PnP (Plug and Play) and PCI expansion cards
operate in your system. Both the the ISA and PCI buses on the motherboard
use system IRQs (Interrup ReQuests) and DMAs (Direct Memory Access).
You must set up the IRQ and DMA assignments correctly through the
PnP/PCI Configurations Setup utility for the motherboard to work properly.
Selecting PnP/PCI Configurations on the main program screen displays this
menu:
Phoenix-AwardBIOS CMOS Setup Utility
PnP/PCI Configurations
Reset Configuration Data [Disabled]
Resources Controlled By [Auto(ESCD)]
IRQ Resources Press Enter
PCI/VGA Palette Snoop [Disabled]
Assign IRQ For USB [Enabled]
Item Help

Menu Level

F5:Previous Values F6:Performance Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
X
Default is Disabled. Select
Enabled to reset Extended
System Configuration Data
ESCD) when you exit Setup if
you have installed a new add-
on and the system
reconfiguration has caused
such a serious conflict that
the OS cannot boot
Reset Configuration Data [Disabled]
If you enable this item and restart the system, any Plug and Play configuration data
stored in the BIOS Setup is cleared from memory.
 IRQs Activity Monitoring (Press Enter)
This screen enables you to set IRQs that will resume the system from a power saving
mode.
Phoenix-AwardBIOS CMOS Setup Utility
IRQs Activity Monitoring
Primary INTR [ON]
IRQ4 (COM1) [Enabled]
IRQ5 (LPT2) [Enabled]
IRQ6 (Floppy Disk) [Enabled]
IRQ7 (LPT1) [Enabled]
IRQ8 (RTC Alarm) [Disabled]
IRQ9 (IRQ2 Redir) [Disabled]
IRQ10 (Reserved) [Disabled]
IRQ11 (Reserved) [Disabled]
IRQ12 (PS/2 Mouse) [Enabled]
IRQ13 (Coprocessor) [Enabled]
IRQ14 (Hard Disk) [Enabled]
IRQ15 (Reserved) [Disabled]
Item Help

Menu Level

F5:Previous Values F6:Performance Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
Set any IRQ to Enabled to allow activity at the IRQ to wake up the system from a
power saving mode.
Press <Esc> to return to the IRQ/Event Activity Detect pages
