ECS KV2 Extreme User Manual

5-5
Press “Y” to confirm or “N” to return to the configuration options.
5.1-6 Delete Array
Press “Y” to confirm or “N” to return to the configuration options.
1 In the VIA RAID BIOS utility main menu, select Delete Array
then press the <Enter> key. The focus is directed to the list of
channel used for IDE RAID arrays.
2 Press the <Enter> key to select a RAID array to delete. The
following confirmation message appears.
5.1-7 Select Boot Array
1 In the VIA RAID BIOS utility main menu, select Boot Array then
press the <Enter> key. The focus is directed to the list of channel
used for IDE RAID arrays.
2 Press the <Enter> key to select a RAID array for boot. The Status
of the selected array will change to Boot. Press <ESC> key to go
return to menu items. Follow the same procedure to deselect the
boot array.

ECS KV2 Extreme Specifications

General

Brand	ECS
Model	KV2 Extreme
Category	Motherboard
Language	English
