Resources Controlled By [Auto(ESCD)]
You should leave this item at the default Auto (ESCD). Under this setting, the
system dynamically allocates resources to Plug and Play devices as they are
required.
If you cannot get a legacy ISA (Industry Standard Architecture) expansion card to
work properly, you might be able to solve the problem by changing this item to
Manual, and then opening up the IRQ Resources submenu.
IRQ Resources [Press Enter]
In the IRQ Resources submenu, if you assign an IRQ to Legacy ISA, then that
Interrupt Request Line is reserved for a legacy ISA expansion card. Press <Esc> to
close the IRQ Resources submenu.
PCI/VGA Palette Snoop [Disabled]
This item is designed to overcome problems that can be caused by some non-
standard VGA cards. This board includes a built-in VGA system that does not require
palette snooping so you must leave this item disabled.
Assign IRQ For USB [Enabled]
Names the interrupt request (IRQ) line assigned to the USB on your system.
Activity of the selected IRQ always awakens the system.
3.3-7 PC Health Status
On motherboards that support hardware monitoring, this item lets you
monitor the parameters for critical voltages, temperatures and fan speeds.
Phoenix-AwardBIOS CMOS Setup Utility
PC Health Status
Shutdown Temperature [Disabled]
CPU Vcore
3.30 V
5.00 V
+12 V
Voltage Battery
Current System Temp
Current CPU Temp
CPUFAN1 Speed
CASFAN1 Speed
Item Help
Menu Level
F5:Previous Values F6:Performance Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
Shutdown Temperature [Disabled]
Enables you to set the maximum temperature the system can reach before powering
down.
System Component Characteristics
These fields provide you with information about the systems current operating
status. You cannot make changes to these fields.
