SOI/DT 2002-06 eb 14 599 35 27-25
2.9 Programme phase LEDs
When the programme has been selected, the LEDs
corresponding to the various phases in the programme light.
When the programme starts, only the LED corresponding to the
current phase remains lit.
LED Colour Models with Display Models without Display
L26
Green -- Door Prewash Door
L27
Green Prewash Prewash Wash Wash
L28
Green Wash Wash Rinses Wash
L29
Green Rinses Rinses Rinse hold Rinses
L30
Green Spin Spin Spin Spin
L31
Green Drain Drain Drain Drain
L32
Orange
Drying (only for
washer-dryers)
Drying (only for
washer-dryers)
Filter Clogged Filter Clogged
L33
Green -- -- End End
Door LED
The following table shows the door LED the function:
Led Status Meaning
On While the cycle is performing with the possibility to open the door (in pause
mode)
Flashing Cycle in pause mode without the possibility to open the door (closed door)
Off While the cycle is performing without the possibility to open the door (in
pause mode) or door open
2.10 Display
The display shows the following information:
Ö Three flashing hyphens: when a programme is cancelled by
pressing the SKIP/RESET button. The hyphens will also be displayed
when the ON/OFF button is pressed to switch the appliance on, but
only if the cycle selected previously has been cancelled.
Ö The duration of the washing programme is displayed when the
programme has been selected. This time corresponds to the time
necessary for the maximum wash load.
When the programme is started (i.e. after pressing START/PAUSE),
the time is decremented at intervals of one minute.
Ö The drying programme duration (washer-dryers), which is
displayed during the phase of selection of the drying time. After two
seconds the total time corresponding to half wash load is shown up.
In non-stop cycles the time results from the wash plus drying time.
