7.9.2 Example of configuration
Configuration code:
A2A7808080E691F2
POSITION:
0 1 2 3 4 5 6 7 8 9 10
(A)
11
(B)
12
(C)
13
(D)
14
(E)
15
(F)
↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓
VALUE: A 2 A 7 8 0 8 0 8 0 E 6 9 1 F 2
Table of cycle phases Leds
On models not featuring the display window, it is advisable, before beginning the configuration procedure, to
convert the digits of the configuration code into binary format (the positions, indicated by the second group
of 4 LEDs, are not modified).
0
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
A
b C d E F
❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ● ● ● ● ● ● ● ●
❍ ❍ ❍ ❍ ● ● ● ● ❍ ❍ ❍ ❍ ● ● ● ●
❍ ❍ ● ● ❍ ❍ ● ● ❍ ❍ ● ● ❍ ❍ ● ●
POSITION
❍ ● ❍ ● ❍ ● ❍ ● ❍ ● ❍ ● ❍ ● ❍ ●
● ❍ ● ❍ ● ❍ ● ❍ ● ❍ ● ❍ ● ❍ ● ❍
❍ ❍ ❍ ● ❍ ❍ ❍ ❍ ❍ ❍ ● ● ❍ ❍ ● ❍
● ● ● ● ❍ ❍ ❍ ❍ ❍ ❍ ● ● ❍ ❍ ● ●
❍ ❍ ❍ ● ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ ● ● ● ❍ VALUE
A 2 A 7 8 0 8 0 8 0 E 6 9 1 F 2
CONFIGURATION
1. Access the diagnostics system.
2. Press the FABRICS (1) or TEMPERATURE (2) buttons until LED L10 lights. The code relative to the first
of the 16 characters of the configuration code is displayed (position zero).
3. Press the START/PAUSE button (7) sequentially to enter the letter A in position 0. If the appliance
features a display window, this will show 0-A; if not, the wash cycle LEDs should light as shown in column
0 of the table (i.e. the fifth and seventh LEDs).
4. Press the SKIP/RESET button (8) to pass to the second position, and enter 2 by pressing START/PAUSE
(7) as necessary. The display should now show 1-2, and the LEDs should light as shown in column 1 of
the table (fourth and seventh).
5. Repeat this procedure to enter the remaining configuration digits. When all the digits have been entered,
press the SKIP/RESET button (8) to check that the configuration code is correct.
6. Memorize the configuration code by pressing the START/PAUSE (7) and SKIP/RESET (8) buttons at the
same time for at least 4 seconds, so that the configuration code is memorized by the main PCB.
7. Perform the diagnostics cycle to check that the appliance operates correctly. In case of a configuration
error, error E93 is displayed and the operation of the appliance is interrupted).
