10.3 Key to circuit diagram
1. Main PCB
2. Control/display board
5. Anti-interference filter
6. ON/OFF button
6a.Pilot lamp
7. Door interlock
8. Analog pressure switch (electronic)
9. NTC temperature sensor (washing)
10. Anti-boiling pressure switch 1
11. Heating element (washing)
13. Motor
12. Anti-boiling pressure switch 2
14. Recirculation pump (jetsystem models)
15. Drain pump
16. Pre-wash solenoid
17. Wash solenoid
18. Bleach solenoid or hot water solenoid (certain models only)
19. AC/DC converter (certain models only)
20. Door lamp
Washer/dryers only
21. Condensation solenoid
22. Safety thermostat
23. Heating element (drying)
24. Manual-reset safety thermostat
25. NTC temperature sensor (drying time)
26. NTC temperature sensor (drying)
27. Fan motor
