Electrolux AWF 1210 User Manual

TSE-P 02.00 EB 21/60 599 35 24-30
4.3 Synthetics 40°C (Jetsystem)
(W2C01450) Synthetics 40 JETSYSTEM
N. Phase Description
Levels
(mm H
2
O)
Rec.
pump
Drain
pump
Elv / Det
comp.
Movement Refilling
Temp.
°C
Time
0 CALIBRATION 35/15 OFF ON OFF Dis Tout 10'
1 Washing WATER FILL 40/15 OFF OFF ELV2 OFF NR Tout 15'
2 MOVEMENT 40/15 OFF OFF ELV2 PWL3_MOV NR 1'
3 WATER FILL 100/65 LEV OFF ELV3 OFF NR Tout 15'
4 MOVEMENT 100/65 LEV OFF ELV3 N_MOV NR 7'
5 HEATING 100/65 ON OFF ELV3 N_MOV NR 38 Tout 40'
6 MOVEMENT 100/65 LEV OFF ELV3 N_MOV NR 8'
7 HEATING 100/65 ON OFF ELV3 E_MOV NR 40 Tout 40'
8 MOVEMENT 100/65 LEV OFF ELV3 D_MOV NR 3'
9 MOVEMENT 100/65 LEV OFF ELV3 E_MOV NR 7'
10 HEAT+MOV 100/65 ON OFF ELV3 D_MOV NR 40 3'
11 MOVEMENT 100/65 LEV OFF ELV3 E_MOV NR 6'
12 WATER FILL 160/80 LEV OFF ELV3 N_MOV NR Tout 1'
13 MOVEMENT LEV OFF N_MOV Dis 1'
14 MOVEMENT LEV OFF N_MOV Dis 1'
15 WATER DRAIN OFF Lev OFF Dis Tout 10'
16
TIME WATER
DRAIN
OFF ON OFF Dis 30''
17
TIME WATER
DRAIN
OFF ON E_MOV Dis 30''
18
TIME WATER
DRAIN
OFF ON E_MOV Dis 1'
19 1
st
Rinse MOVEMENT OFF OFF OFF Dis 5''
20 WATER FILL 160/80 LEV OFF ELV3 OFF NR Tout 15'
21 MOVEMENT 160/80 LEV OFF ELV3 N_MOV NR 2'
22 WATER DRAIN LEV Lev E_MOV Dis Tout 10'
23
TIME WATER
DRAIN
LEV ON E_MOV Dis 2'
24 2
nd
Rinse MOVEMENT LEV OFF OFF Dis 5''
25 WATER FILL 160/80 LEV OFF ELV3 OFF NR Tout 15'
26 MOVEMENT 160/80 LEV OFF ELV3 N_MOV NR 2'
27 WATER DRAIN OFF Lev E_MOV Dis Tout 10'
28 SPINNING OFF ON IMP_C0_INP_SECT Dis Tout 20'
29 SPINNING OFF ON IMP_C0_SP_SECT Dis Tout 20'
30 3
rd
Rinse MOVEMENT OFF OFF OFF Dis 5''
31 (softener) WATER FILL 100/65 OFF OFF
ELV2
ELV3
OFF NR Tout 15'
32 MOVEMENT OFF OFF
ELV2
ELV3
N_MOV NR 30''
33 MOVEMENT OFF OFF
ELV2
ELV3
OFF NR 5''
34 WATER FILL 160/80 LEV OFF
ELV2
ELV3
OFF NR Tout 15'
35 MOVEMENT 160/80 LEV OFF
ELV2
ELV3
N_MOV NR 2'
36 MOVEMENT 160/80 LEV OFF
ELV2
ELV3
N_MOV NR 3'
37 Spinning WATER DRAIN OFF Lev OFF Dis Tout 10'
38
TIME WATER
DRAIN
OFF ON OFF Dis 15''
39 SPINNING OFF OFF IMP5 Dis Tout 20'
40 MOVEMENT OFF OFF N_MOV Dis 1'
