Electrolux AWF 1210 User Manual

TSE-P 02.00 EB 23/60 599 35 24-30
4.5 Hand wash 30º (Jetsystem)
(W2C01450) Handwash 30 JETSYSTEM
N. Phase Description
Levels
(mm H
2
O)
Rec.
pump
Drain
pump
Elv / Det
comp.
Movement
Refillin
g
Temp.
°C
Time
0 CALIBRATION 35/15 OFF ON OFF Dis Tout 10'
1 Washing WATER FILL 40/15 OFF OFF ELV2 OFF NR Tout 15'
2 MOVEMENT 40/15 OFF OFF ELV2 PWL3_MOV NR 1'
3 WATER FILL 115/50 LEV OFF ELV3 OFF NR Tout 15'
4 MOVEMENT 115/50 LEV OFF ELV3 PWL4_MOV NR 4'
5 HEATING 115/50 ON OFF ELV3 PWL4_MOV NR 30 Tout 40'
6 MOVEMENT 115/50 LEV OFF ELV3 PWL4_MOV NR 2'
7 HEAT+MOV 115/50 LEV OFF ELV3 PWL4_MOV NR 30 14'
8 WATER DRAIN OFF Lev OFF Dis Tout 10'
9
TIME WATER
DRAIN
OFF ON OFF Dis 1'
10 1
st
Rinse MOVEMENT OFF OFF OFF Dis 5''
11 WATER FILL 160/80 LEV OFF ELV3 OFF NR Tout 15'
12 MOVEMENT 160/80 LEV OFF ELV3 PWL4_MOV NR 3'
13 WATER DRAIN OFF Lev OFF Dis Tout 10'
14
TIME WATER
DRAIN
OFF ON OFF Dis 1'
15 2
nd
Rinse MOVEMENT OFF OFF OFF Dis 5''
16 WATER FILL 160/80 LEV OFF ELV3 OFF NR Tout 15'
17 MOVEMENT 160/80 LEV OFF ELV3 PWL4_MOV NR 3'
18 WATER DRAIN OFF Lev OFF Dis Tout 10'
19
TIME WATER
DRAIN
OFF ON OFF Dis 1'
20 3
rd
Rinse MOVEMENT OFF OFF OFF Dis 5''
21 (softener) WATER FILL 115/50 OFF OFF ELV2 ELV3 OFF NR Tout 15'
22 MOVEMENT 115/50 OFF OFF ELV2 ELV3 N_MOV NR 30''
23 WATER FILL 160/80 LEV OFF ELV2 ELV3 OFF NR Tout 15'
24 MOVEMENT 160/80 LEV OFF ELV2 ELV3 PWL4_MOV NR 5'
25 Spinning WATER DRAIN OFF Lev OFF Dis Tout 10'
26 SPINNING OFF ON IMP4 Dis Tout 20'
27 MOVEMENT OFF OFF N_MOV Dis 1'
4.6 30º Hand wash (Traditional/Eco-ball)
(W2C01450) ) Handwash 30 TRADITIONAL
Levels
(mm H
2
O)
N. Phase Description
Ecoball Tradit.
Drain
pump
Elv / Det
comp.
Movement Refilling
Temp.
°C
Time
0 CALIBRATION 40/15 40/15 ON OFF Dis Tout 10'
1 Washing WATER FILL 40/15 40/15 OFF ELV2 OFF NR Tout 15'
2 MOVEMENT 40/15 40/15 OFF ELV2 PWL3_MOV NR 1'
3 WATER FILL 140/90 150/80 OFF ELV3 OFF NR Tout 15'
4 MOVEMENT 140/90 150/80 OFF ELV3 PWL4_MOV NR 4'
5 HEATING 140/90 150/80 OFF ELV3 PWL4_MOV NR 30 Tout 40'
6 MOVEMENT 140/90 150/80 OFF ELV3 PWL4_MOV NR 2'
7 HEAT+MOV 140/90 150/80 OFF ELV3 PWL4_MOV NR 30 14'
8 WATER DRAIN Lev OFF Dis Tout 10'
9
TIME WATER
DRAIN
ON OFF Dis 1'
10 1
st
Rinse MOVEMENT OFF OFF Dis 5''
11 WATER FILL 135/85 155/110 OFF ELV3 OFF NR Tout 15'
12 MOVEMENT 135/85 155/110 OFF ELV3 PWL4_MOV NR 3'
13 WATER DRAIN Lev OFF Dis Tout 10'
14
TIME WATER
DRAIN
ON OFF Dis 1'
15 2
nd
Rinse MOVEMENT OFF OFF Dis 5''
16 WATER FILL 135/85 155/110 OFF ELV3 OFF NR Tout 15'
17 MOVEMENT 135/85 155/110 OFF ELV3 PWL4_MOV NR 3'
18 WATER DRAIN Lev OFF Dis Tout 10'
19
TIME WATER
DRAIN
ON OFF Dis 1'
20 3
rd
Rinse MOVEMENT OFF OFF Dis 5''
21 (softener) WATER FILL 140/90 150/80 OFF ELV2 ELV3 OFF En Tout 15'
22 MOVEMENT 140/90 150/80 OFF ELV2 ELV3 N_MOV En 30''
23 WATER FILL 135/85 155/110 OFF ELV2 ELV3 OFF En Tout 15'
24 MOVEMENT 135/85 155/110 OFF ELV2 ELV3 PWL4_MOV En 5'
25 Spinning WATER DRAIN Lev OFF Dis Tout 10'
26 SPINNING ON IMP4 Dis Tout 20'
27 MOVEMENT OFF N_MOV Dis 1'
