Rate input settings (continued)Table 1-2:
Setting Description
Accuracy ±0.03% of calibrated span ±1 count
Temperature drift Rate display is not affected by changes in temperature.
Low-flow cutoff 0-99,999 (0 disables cutoff function)
Decimal point Up to four decimal places or none:
4.4444, 33.333, 222.22, 1111.1, or 00000
Calibration May be calibrated using K-Factor, scale without signal source, or by ap-
plying an external calibration signal.
K-Factor Field programmable K-Factor converts input pulses to rate in engineer-
ing units. May be programmed from 0.000001 to 9,999,999 pulses/unit.
Calibration range Input 1 signal must be ≥ 1 Hz; input 2 signal may be set anywhere above
input 1 setting.
Minimum input span is 1 Hz.
An Error message will appear if the input 1 and input 2 signals are too
close together.
Input contact de-
bounce filter
Programmable contact debounce filter. Input signal frequency speed se-
lections of Hi (no filter), Med (250 Hz max input, 2 ms pulse width), and
Low (100 Hz max input, 5 ms minimum pulse width).
Time base Second, minute, hour, or day
Gate Low gate: 1-99 seconds; High gate: 2-9,999 seconds
1.4 Rate/Internal Display settings
The settings below are rate/display specifications for the Internal Display. Except when
noted, all specifications apply to operation at +25°C (+77°F).
Table 1-3: Rate/Internal display settings
Setting Display
Display assignment The Top display calculates rate or total. The Bottom displays total; total and
units; total and tag; total, total units, and rate units; grand total; grand to-
tal and grand total units; grand total and tag; grand total, grand total units,
and rate units; rate units; rate; rate and total units; rate and rate units; rate
and tag; rate units; total units; a custom tag; or be off (blank).
Rate display units Gallons, liters, imperial gallons, cubic meters, barrels, bushels, cubic yards,
cubic feet, cubic inches, liquid barrels, beer barrels, hectoliters, or custom.
Rate display time
base
Display rate may be calculated in terms of units per second, minute, hour,
or day.
Total and grand total
display units
Gallons, liters, imperial gallons, cubic meters, barrels, bushels, cubic yards,
cubic feet, cubic inches, liquid barrels, beer barrels, hectoliters, or custom.
Setting is independent for each.
Introduction
User manual 7
