Button operationTable 5-2:
Button Procedure
Menu •
Hold the Menu button when in Power Save Mode ( will display) to
awaken through-glass buttons.
• Press the Menu button to enter Programming Mode.
• Press the Menu button during Programming Mode to return to the previ-
ous menu selections.
• Hold the Menu button for 1.5 seconds at any time to exit Programming
Mode and return to Run Mode.
• Press and hold the Menu button for 3 seconds to access the Advanced fea-
tures of the meter.
• Press Menu while displaying grand total, max, or min reading to return to
Run mode.
Right/Reset • Press the Right arrow button to move to the next digit or decimal position
during programming.
• Press Right to go backward through most selection menus.
• Press Right to reset the total, or values displayed in the bottom display
(grand total, max, or min).
• Press Enter after Right to confirm the reset.
Up/Display • Press Display when in Run mode to display the grand total, again to dis-
play the maximum, and again to display the minimum reading since last
reset. These displays will time out in 12 seconds, or press Display until to-
tal is displayed in the lower display. Press Enter to lock this display, and dis-
able the 12 second time out.
• Press the Up arrow button to scroll forward through the menus, decimal
point, or to increment the value of a digit.
Enter • Press the Enter button to access a menu or to accept a setting.
• Press Enter to lock the grand total, maximum or minimum value display,
and disable the 12 second time out.
• Press Enter to acknowledge alarm (if enabled).
• Press Enter to lock display of grand total, Max or Min readings (disables 10
second timeout).
5.2 Button tips
The through-glass buttons are designed to filter normal levels of ambient interference and
to protect against false triggering. However it is recommended that the through-glass
buttons be turned off (slide THRU-GLASS BUTTONS switch to OFF) if there is an infrared
interference source in line-of-sight to the display or if the buttons are not needed.
1. Install the display facing away from sunlight, windows, reflective objects and any
sources of infrared interference.
2. Keep the glass window clean.
3. Tighten the cover securely.
4. Use a password to prevent tampering.
Setup and programming
User manual 31
