108 Appendix 2 Accessories
EV2000 Series Universal Variable Speed Drive User Manual
Appendix 2 Accessories
 Notes:
Our company does not supply reactor and EMI filter, so
you should order them separately. The following models
have been tested on our drive. You can contact us if you
need them.
AC/DC Reactor
AC input reactor and output reactor
1. Model description
AC input reactor: TDL-4AI01-0300, where 0300 denotes
the power level, similar to the power level of the drive.
AC output reactor: TDL-4AO01-0300, where 0300
denotes the power level, similar to the power level of the
drive.
2. Sizes
The sizes of AC input reactor and output reactor are
classified into three types, as shown in Fig. A-1 ~
Fig.A-3. See Table A-2 ~ Table A-4 for the details.
h
b1
n2
n1
L2
L1
4- d
Fig. A-1 Outline of 3-PH AC input and output reactor (a)
h
b1
n2
n1
L2
L1
e
4- d
Fig. A-2 Outline of 3-PH AC input and output reactor (b)
L3
h
b1
n2
n1
L2
e
L1
4- d
Fig. A-3 Outline of 3-PH AC input and output reactor (c)
