60 Chapter 5 Parameter Introductions
EV2000 Series Universal Variable Speed Drive User Manual
The drive will first operate at preset frequency of
traverse operation (F6.02) for certain time (F6.03), and
then enter traverse mode automatically.
1: Manual mode
If the multi-function terminal (Xi is set to No.33 function)
is enabled, the drive will enter traverse mode. If the
terminal is disabled, the drive will end traverse operation
and operate at the pre-traverse frequency (F6.02).
Ten’s place: traverse operating amplitude
0: variable amplitude
Traverse operating amplitude AW changes with the
central frequency and the change rate is defined by
F6.04.
1: Fixed amplitude
Traverse operating amplitude AW is determined by Max
frequency and F6.04.
Hundred’s place: start mode of traverse operation
0: The drive starts and runs at the frequency and
direction before it stops
1: Restart
Thousand’s place: saving the traverse operating
parameters upon power outage
The traverse operating parameters can be saved when
power outage occurs. The function is effective when the
hundred’s place is set at 0.
0: save
1: not save
Note:
Terminal Xi (No. 34 function) can be used to reset the
traverse operating status.
F6.02 Pre-traverse frequency
Range: 0.00Hz~650.0Hz
【0.00Hz】
F6.03 Holding time of
Pre-traverse frequency
Range:0.0~3600.0s
【0.0s】
F6.02 is used to define the drive’s operating frequency
before entering traverse mode.
If auto-start mode is selected, F6.03 is used to define
the time when the drive operates at pre-traverse
frequency. If manual start mode is selected, F6.03 is
disabled.
Refer to Fig. 5-37.
F6.04 Traverse amplitude
Range:0.0~50.0%【0.0%】
variable amplitude: AW = central frequency × F6.04
Fixed amplitude: AW = Max operating frequency
F0.05×F6.04
Note:
The traverse operating frequency is restricted by the upper
and lower limit of frequency. Traverse operation will be
abnormal if the frequency is set incorrectly.
F6.05 Jitter frequency
Range:0.0~50.0%(ratio to
amplitude)【0.0%】
As shown in Fig. 5-37, there is no jitter frequency if
F6.05 is set to 0.
F6.06 Traverse operating
cycle
Range:0.1~999.9s【10.0s】
F6.06 defines a complete cycle of traverse operation
including rising and falling processes.
Note:
In traverse mode, do not select auto Acc/Dec operating
mode, otherwise the traverse operating cycle will be
abnormal.
F6.07 Rising time of triangle
wave
Range:0~100.0%【50.0%】
Rising time of traverse operation＝F6.06×F6.07.
Falling time of traverse operation
＝F6.06×(1-F6.07)
The unit is second. Refer to Fig. 5-37.
Note:
You can select traverse mode and S curve at the same, thus
the traverse operation is much more smoother.
5.8 Function of Terminals(Group F7)
F7.00 Multi-function terminal X1
Range:0~43【0】
F7.01 Multi-function terminal X2
Range:0~43【0】
F7.02 Multi-function terminal X3
Range:0~43【0】
F7.03 Multi-function terminal X4
Range:0~43【0】
F7.04 Multi-function terminal X5
Range:0~43【0】
F7.05 Multi-function terminal X6
Range:0~43【0】
F7.06 Multi-function terminal X7
Range:0~47【0】
F7.07 Multi-function terminal X8
Range:0~48【0】
The functions of multi-function input terminal X1~X8 are
extensive. You can select functions of X1~X8 according
to your application by setting F7.00~F7.07. Refer to
Table 5-5.
Table 5-5 Multi-function selection
Setting Functions
0 No function
1 Preset frequency 1
2 Preset frequency 2
3 Preset frequency 3
4 Acc/Dec time 1
