EV2000 Series Universal Variable Speed Drive User Manual
Appendix 3 Communication Protocol
1 Networking Mode
RS232
Master: PC
RS485
Master: PC
TD1000
TD2000
TD2100 EV2000
RS232
Master: PC
EV2000
adapter
Single master and multi-slave
Single master and single slave
or
RS485
RS232
Master: PC
EV2000
RS232-RS485
adapter
RS232-RS485
Fig. A-6 Networking diagram of drives
2 Interfaces
RS485 or RS232: asynchronous, semi-duplex
Default: 8-N-1, 9600bps. See Group FF for parameter settings.
3 Communication Modes
The drive is a slave in the network. It communicates in ‘point to point’ mode. The drive will not response to the
command sent by the master via broadcast address.
Users can set the drive’s current address, baud rate and data format by using the drive’ keypad or through the serial
communication port.
The drive can report the current fault information when polled by the master.
EV2000 provides two interfaces: RS232 and RS485. Pay attention that the Jumper CN14 should be in correct position.
