Emerson Quantum MP User Manual

Safety
Information
Product
Information
Mechanical
Installation
Electrical
Installation
Getting
Started
Basic
parameters
Running the
Motor
Optimization
SMARTCARD
Operation
Onboard
PLC
Advanced
Parameters
Technical
Data
Diagnostics
UL
Information
140 Quantum MP User Guide
www.emersonct.com Issue: A4
11.17 Menu 18: Application menu 1
11.18 Menu 19: Application menu 2
11.19 Menu 20: Application menu 3
All menu 20 parameters are transferred to the SMARTCARD when a 4yyy transfer is performed. See section 9.3.1 Writing to the SMARTCARD on
page 82 for more information.
17.28 Relay 2 source PR 0.00 to PR 21.51 PR 6.55 RW Uni US
17.50 Solutions Module error status 0 to 255
RO Uni NC PT
17.51 Solutions Module software sub-version 0 to 99
RO Uni NC PT
Parameter
Range(
)Default()
Type
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
Parameter
Range(
) Default()
Type
18.01
Application menu 1 power-down
saved integer
-32,768 to +32,767 0 RW Bi NC PS
18.02 to
18.10
Application menu 1 read-only integer -32,768 to +32,767 0 RO Bi NC
18.11 to
18.30
Application menu 1 read-write integer -32,768 to +32,767 0 RW Bi US
18.31 to
18.50
Application menu 1 read-write bit OFF (0) or On (1)
0
RW Bit US
Parameter
Range(
) Default()
Type
19.01
Application menu 2 power-down
saved integer
-32,768 to +32,767 0 RW Bi NC PS
19.02 to
19.10
Application menu 2 read-only integer -32,768 to +32,767 0 RO Bi NC
19.11 to
19.30
Application menu 2 read-write integer -32,768 to +32,767 0 RW Bi US
19.31 to
19.50
Application menu 2 read-write bit OFF (0) or On (1) 0 RW Bit US
Parameter
Range(
) Default()
Type
20.01 to
20.20
Application menu 3 read-write integer -32,768 to +32,767 0 RW Bi NC
20.21 to
20.40
Application menu 3 read-write long
integer
-2
31
to 2
31
-1
0 RW Bi NC
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
