60 Quantum MP User Guide
www.emersonct.com Issue: A4
5.7 Advanced menus
The advanced menus consist of groups or parameters appropriate to a
specific function or feature of the drive. Menus 0 to 23 can be viewed on
both keypads. Menus 40 and 41 are specific to the SM-Keypad Plus
(LCD). Menus 70 to 91 can be viewed with an SM-Keypad Plus (LCD)
only when an SM-Applications module is installed.
Table 5-2 Advanced menu descriptions
Table 5-3 Menu 40 parameter descriptions
Table 5-4 Menu 41 parameter descriptions
5.8 Saving parameters
When changing a parameter in Menu 0, the new value is saved when
pressing the Mode button to return to parameter view mode from
parameter edit mode.
If parameters have been changed in the advanced menus, then the
change will not be saved automatically. A save function must be carried
out.
Procedure
1. Enter SAVE in Pr xx.00
2. Either:
• Press the red reset button
• Toggle the reset digital input, or
• Carry out a drive reset through serial communications by
setting Pr 10.38 to 100 (ensure that Pr xx.00 returns to 0).
Menu Description LED LCD
0
Commonly used basic set up parameters for quick
/ easy programming

1
Speed reference 
2
Ramps 
3
Speed feedback and speed control 
4
Torque and current control 
5
Motor control including field regulator 
6
Sequencer and clock 
7
Analog I/O 
8
Digital I/O 
9
Programmable logic, motorized pot and binary
sum

10
Status and trips 
11
General drive set-up 
12
Threshold detectors and variable selectors 
13
Position control 
14
User PID controller 
15
Solutions Module set-up 
16
Solutions Module set-up 
17
Solutions Module set-up 
18
Application menu 1 
19
Application menu 2 
20
Application menu 3 
21
Second motor parameters 
22
Menu 0 set-up - user area 
23
Menu 0 sub block control 
40
Keypad configuration menu X 
41
User filter menu X 
70
PLC registers X 
71
PLC registers X 
72
PLC registers X 
73
PLC registers X 
74
PLC registers X 
75
PLC registers X 
85
Timer function parameters X 
86
Digital I/O parameters X 
88
Status parameters X 
90
General parameters X 
91
Fast access parameters X 
Parameter
Range(
)
40.00
Parameter 0 0 to 32767
40.01
Language selection
English (0), Custom (1),
French (2), German (3),
Spanish (4), Italian (5)
40.02
Software version 999999
40.03 Save to flash
Idle (0), Save (1), Restore (2),
Default (3)
40.04
LCD contrast 0 to 31
40.05
Drive and attribute
database upload was
bypassed
Updated (0), Bypass (1)
40.06
Browsing favourites
control
Normal (0), Filter (1)
40.07
Keypad security code 0 to 999
40.08
Communication channel
selection
Disable (0), Slot1 (1), Slot2 (2),
Slot3 (3), Slave (4), Direct (5)
40.09
Hardware key code 0 to 999
40.10
Drive node ID (Address) 0 to 255
40.11
Flash ROM memory size 4Mbit (0), 8Mbit (1)
40.19
String database version
number
0 to 999999
40.20
Shield saver strings and
enable
None (0), Default (1), User (2)
40.21
Shield saver interval 0 to 600
40.22
Turbo browse time
interval
0 to 200 ms
40.23
Connected drive type
Unidrive SP (0),
Commander SK (1), Mentor/
Quantum (2), Commander
GP20 (3),
Affinity (4), Digitax ST (5)
Parameter
Range(
)
41.00
Parameter 0 0 to 32767
41.01 to
41.50
Browsing filter source F01 to
F50
Pr 0.00 to Pr 22.99
41.51
Browsing favourites control Normal (0), Filter (1)
