9.6 SMARTCARD trips
After an attempt to read, write or erase data to or from a SMARTCARD a trip may occur if there has been a problem with the command. Table 9-6 lists
the trip indications and conditions that will cause the SMARTCARD to trip,
Table 9-6 Trip conditions
Trip Condition
C.boot
SMARTCARD trip: The menu 0 parameter modification cannot be saved to the SMARTCARD because the necessary
file has not been created on the SMARTCARD
177
A write to a Menu 0 parameter has been initiated with the keypad by exiting edit mode and Pr 11.42 (SE09, 0.30) is set for
auto or boot mode. However the necessary boot file has not been created on the SMARTCARD to take the new parameter
value. This occurs when Pr 11.42 (SE09, 0.30) is changed to auto or boot mode, but the drive is not subsequently reset.
C.BUSy
SMARTCARD trip: SMARTCARD can not perform the required function as it is being accessed by a Solutions
Module
178
An attempt has been made to access a SMARTCARD. However an Solutions Module is already accessing the
SMARTCARD.
C.Chg SMARTCARD trip: Data location already contains data
179 An attempt has been made to store data in a SMARTCARD data block that already exists.
C.Optn SMARTCARD trip: Solutions Modules installed are different between source drive and destination drive
180
Parameter data or default difference data is being transferred from a SMARTCARD to the drive, but the Solutions Module
categories are different between source and destination drives. This trip does not stop the data transfer, but is a warning that
the data for the Solutions Modules that are different will be set to the default values and not the values from the card. This trip
also applies if a compare is attempted between the data block and the drive.
C.Rdo SMARTCARD trip: SMARTCARD has the Read Only bit set
181
An attempt has been made to modify a read-only SMARTCARD (i.e. erase the card, erase a file or create a file). A
SMARTCARD is read-only if the read-only flag has been set or the card contains data blocks with numbers from 500 to 999.
Attempting to create data blocks with numbers from 500 to 999 will always cause a trip.
C.Err SMARTCARD trip: SMARTCARD data is corrupted
182
An attempt has been made to transfer a data block from a SMARTCARD to the drive or to compare a SMARTCARD data
block and the checksum is incorrect or the data structure on the card is incorrect.
C.dat SMARTCARD trip: Data location specified does not contain any data
183
An attempt has been made to transfer a data block from a SMARTCARD to the drive or to compare a SMARTCARD data
block and the block does not exist.
C.FULL SMARTCARD trip: SMARTCARD full
184 An attempt has been made to create a data block on a SMARTCARD, but there is not enough space on the card.
C.Acc SMARTCARD trip: SMARTCARD Read / Write fail
185
An attempt has been made to access a SMARTCARD, but a card is not present or communications failure has occurred
between the drive and the card. This trip is also produced if an attempt is made to access a data block that has already been
opened by an Solutions Module.
C.rtg SMARTCARD trip: The voltage and/or current rating of the source and destination drives are different
186
Parameter data or default difference data is being transferred from a SMARTCARD to the drive, but the current and /or
voltage ratings are different between source and destination drives. This trip does not stop the data transfer, but is a warning
that the data for the Solutions Modules that are different will be set to the default values and not the values from the card. This
trip also applies if a compare is attempted between the data block and the drive.
C.Typ SMARTCARD trip: SMARTCARD parameter set not compatible with drive
187
This trip is produced during a compare if the drive mode in the data block is different from the current drive mode and the file
is a parameter or defaults differences file. This trip is also produced if an attempt is made to transfer parameters from a
parameter or default difference to the drive if the drive mode in the data block is outside the allowed range of drive modes for
the drive.
C.cpr SMARTCARD trip: The values stored in the drive and the values in the data block on the SMARTCARD are different
188
A compare has been carried out between a data block on a SMARTCARD and the drive and the compare has failed. This trip
only occurs if the compare has not already failed with the following trips: C.Typ, C.rtg, C.Optn, C.BUSy, C.Acc or C.Err.
