12 Technical Data
12.1 Drive technical data
12.1.1 Power and current ratings
The power ratings for the 480V configuration is shown in Table 12-1 .
The continuous current ratings given are for a maximum ambient
temperature of 40°C and an altitude of 1000m. For operation at higher
temperatures and altitudes de-rating is required.
The maximum continuous output current rating of the drive should be
‘de-rated’ for operation at altitudes above 1000m. The de-rating is to be
1% de-rating of rated output current per 100m above 1000m to a
maximum de-rating of 20% at 3000m.
Table 12-1 480V current ratings
12.1.2 Power dissipation
The table below shows the maximum drive losses, assuming high output
current ripple content.
Table 12-2 Drive losses
12.1.3 AC Supply requirements
The standard drive is rated for a nominal supply voltage up to 480 Vrms.
12.1.4 Supply types
Drives rated for supply voltage up to 480V are suitable for use with any
supply type, i.e. TN-S, TN-C-S, TT, IT, with grounding at any potential,
i.e. neutral, centre or corner ("grounded-delta").
12.1.5 SCR bridge AC Supply
Table 12-3 Three phase AC supply
12.1.6 Auxiliary AC supply
Table 12-4 One phase line to line supply
12.1.7 Line reactors
The Quantum MP, in common with all naturally commutated SCR drives,
causes voltage notches at the input supply terminals. In order to avoid
disturbance to other equipment using the same supply, the addition of
external line inductance is strongly recommended in order to restrict the
depth of the notches imposed on the shared supply. This is generally not
necessary where a dedicated transformer is used to supply the drive.
The following recommendations for added line inductance, have been
calculated based on the power drive systems standard: EN61800-
3:2004 “Adjustable speed electrical power drive systems – Part 3: EMC
requirements and specific test methods”.
Table 12-5 Minimum values of L
add
and inductor current rating -
480V supply
1. The above assumes the supply has 1.5% impedance.
2. Assumes a minimum supply rating of 5kA and a maximum rating of
60kA.
12.1.8 Temperature, humidity and cooling method
Ambient temperature operating range:
0°C to 55°C (32°F to 131°F).
Output current derating must be applied at ambient temperatures
>40°C (104°F).
Minimum temperature at power-up:
The drive will power up at -15°C (5°F)
Cooling method:
QMP45A4(R) = Natural convection.
QMP75A4(R) upwards = Forced cooling.
Maximum humidity:
The Quantum MP Product range can operate in environments up to
90% relative humidity at 50°C.
12.1.9 Storage
-40
o
C (-40
o
F) to +55
o
C (131
o
F) for long term storage, or to +70°C
(158°F) for short term storage.
Model
AC input
current
DC output current
Typical motor
power
Continuous
A
Continuous
A
150%
Overload
A
kW @
400
Vdc
hp @
500
Vdc
QMP45A4(R)
40 45 67.5 15 27
QMP75A4(R)
67 75 112.5 27 45
QMP155A4(R)
139 155 232.5 56 90
QMP210A4(R)
188 210 315 75 125
QMP350A4(R)
313 350 525 125 200
QMP400A4(R)
376 400 600 150 250
QMP550A4(R)
492 550 825 200 300
QMP700A4(R)
626 700 1050 250 400
Model
Loss @ 40C Loss @ 50C Loss @ 55C
WWW
QMP45A4(R) >168 >139 >117
QMP75A4(R) >219 >194 >183
QMP155A4(R) >400 >400 >310
QMP210A4(R) >561 >456 >310
QMP350A4(R)
>954
QMP400A4(R)
>1154
QMP550A4(R)
>1568
QMP700A4(R)
>1663
Specification
Product voltage
480V
Max nominal supply 480V
Tolerance +10%
Min nominal supply 24V
Tolerance -20%
Specification Value
Max nominal supply 480V
Tolerance +10%
Min nominal supply 208V
Tolerance -10%
Max supply AC rms. 528V
Min supply AC rms 187V
Model
L
add
Typical
current rating
Maximum
current rating
µH AA
QMP45A4(R) 260 38 40
QMP75A4(R) 260 63 67
QMP155A4(R) 190 130 139
QMP210A4(R) 140 180 188
QMP350A4(R)
85 293 313
QMP400A4(R)
71 351 375
QMP550A4(R)
54 460 492
QMP700A4(R)
43 586 626
