enphase IQ Envoy User Manual

IQ Envoy Installation and Operation
© 2017 Enphase Energy Inc. 141-00039 Rev 01
44
Technical Data
Model Numbers
IQ Envoy
ENV-IQ-AM1-240
Enphase IQ Envoy communications gateway with integrated revenue-grade PV
production metering (ANSI C12.20 +/- 0.5%) and optional consumption monitoring
(+/- 2.5%).
Accessories (order separately)
Enphase Mobile Connect
[Enphase CELLMODEM-01 (3G) or
CELLMODEM-03 (4G)]
Plug and play industrial grade cellular modem with five-year data plan for systems
up to 60 microinverters. (Available where there is adequate cellular service in the
installation area.)
Consumption Monitoring CT
CT-200-SPLIT
Split-core current transformers enable whole home consumption metering (+/- 2.5%).
Wire / Power Requirements / Specifications
Power requirements
120/240 VAC or 208Y/120 VAC, 0.22 A, 60 Hz, OVC III.
When hard wired and installed in an enclosure, the supply wiring must be 14 AWG
copper rated to 75 degrees C or better, and it must be protected by a maximum 15 A
breaker
Relay contacts
240 VAC, OVC II
Pilot duty, B300 (240 V or 120 V, 360 VA)
CT leads
The production CT leads are 1.5m (4.9’) long, 18AWG, and are rated for 200A
The consumption CT leads are 4m (13.1’) long, 18AWG, and are rated for 200A
Capacity
Number of microinverters polled
Up to 600
Mechanical Data
Dimensions (WxHxD)
21.3 x 12.6 x 4.5 cm (8.4” x 5” x 1.8”)
Weight
17.6 oz. (498 g)
Environmental Data
Ambient temperature range
-40° to 65° C (-40° to 149° F)
-40° to 46° C (-40° to 115° F) if installed in an enclosure
Relative Humidity
95%
Environmental rating
IP30. For installation indoors or in an NRTL-certified, NEMA type 3R enclosure
Altitude use
To 2000 meters (6560 feet)
Cooling
Natural convection
