Handling
the
camera
18
18.5
Adjusting
the
viewing
angle
of
the
viewfinder
18.5.1
General
T
o
make
your
working
position
as
comfortable
as
possible,
you
can
adjust
the
viewing
angle
of
the
viewfinder
.
18.5.2
Figure
18.5.3
Procedure
T
o
adjust
the
viewfinder
,
tilt
the
viewfinder
up
or
down.
18.6
Adjusting
the
viewfinder’
s
dioptric
correction
18.6.1
General
The
viewfinder’
s
dioptric
correction
can
be
adjusted
for
your
eyesight.
18.6.2
Figure
#T810169;
r.
AN/42241/42268;
en-US
54
