FLIR GFx320 User Manual

Working with views and images
19
19.1 Saving infrared images
19.1.1 General
You can save one or more images to an SD Memory Card.
19.1.2 Image capacity
The approximate number of images that can be saved on an SD Memory Card is 2,000
per GB.
19.1.3 Saving an infrared image directly to an SD Memory Card
19.1.3.1 General
You can save an image directly to an SD Memory Card, without previewing the image
first.
19.1.3.2 Procedure
Follow this procedure to save an image directly to an SD Memory Card:
1. Turn the mode wheel to
.
2. To save an image without previewing, push and hold the
button for more than
one second.
19.1.4 Previewing and saving an infrared image to an SD Memory Card
19.1.4.1 General
You can preview an image before you save it to an SD Memory Card. This lets you do
one or more of the following tasks before you save the image:
• Edit measurements.
• Adjust the image.
• Add a digital photo.
• Delete an image.
19.1.4.2 Procedure
Follow this procedure to preview and save an image to an SD Memory Card:
1. Turn the mode wheel to
.
2. Push and release the
button. This will display a preview dialog box.
3. You can now do one or more of the following tasks before you save the image. Move
the joystick to go to a task and push the joystick to select the task.
• Select
to edit measurement tools.
• Select
to adjust the image.
• Select
to add a digital photo to the image. You turn on the digital camera
lamps by pushing the joystick. Push the
button to take a digital photo.
• Select
to delete the image.
• Select
to save the image.
#T810169; r. AN/42241/42268; en-US
60
