Handling the camera18
18.9 Adjusting the viewing angle of the display
18.9.1 General
To make your working position as comfortable as possible, you can adjust the viewing
angle of the display.
18.9.2 Figure
18.9.3 Procedure
To adjust the viewing angle of the display, rotate the display clockwise or counter-
clockwise.
18.10 Adjusting the infrared camera focus
Note Do not touch the lens surface when you adjust the infrared camera focus. If this
happens, clean the lens according to the instructions in 35.2 Infrared lens, page 104.
18.10.1 Figure
#T810169; r. AN/42241/42268; en-US
56
