Handling the camera18
18.12 Operating the laser pointer
18.12.1 Figure
18.12.2 Procedure
Follow this procedure to operate the laser pointer:
1. To turn on the laser pointer, push and hold the laser button.
2. To turn off the laser pointer, release the laser button.
WARNING
Do not look directly into the laser beam. The laser beam can cause eye irritation.
Note The symbol is displayed on the screen when the laser pointer is on.
18.13 Laser warning label
A laser warning label with the following information is affixed to the camera:
18.14 Laser rules and regulations
Wavelength: 635 nm. Maximum output power: 1 mW.
This product complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant
to Laser Notice No. 50, dated June 24, 2007.
#T810169; r. AN/42241/42268; en-US
58
