1. Push the ends of the bar on the grille
towards each other and insert them
into the retainers on the roof. Push the
bar forwards into the narrow section
of the retainers.
2. Remove two screws from both the
luggage anchor points. See Luggage
Anchor Points (page 178).
3. Attach the lower bar to the grille with
the handwheels. Do not tighten the
handwheels.
4. Attach the dog guard lower bar to the
luggage anchor points, secure with the
new supplied screws.
5. Tighten the handwheels.
Remove in the reverse order.
LOAD RETAINING FIXTURES
WARNING
Do not exceed the maximum
permissible load of 60 kilogrammes
(132 pounds) on two load retaining
fixtures and 30 kilogrammes (66 pounds)
on one.
Check the security of the load retaining
fixtures and tighten its fittings as follows:
• before starting
• after driving 50 kilometres (30 miles)
• at 1 000 kilometres (600 miles)
intervals.
Installing the load retaining
fixtures
