Circuits protectedAmpere ratingFuse

Cluster IP5F42

Audio/BVC module15F43

Automatic AC / Manual AC5F44

FLR (Start Stop)5F45

Fit a replacement with the same rating as the one you have removed.

Central fuse box

E124888

A B

199

Fuses
