FUSE SPECIFICATION CHART

Engine compartment fuse box

E75525

Circuits protectedAmpere ratingFuse

Transmission control module (AWF21)10F1

Transmission control module (MPS6)15F1

Glow plug monitoring (diesel engines)5F2
