7 Problem Solving
224
When the Lamp [E3] is Lit
1 Make sure that the device has stopped, and press the button on the right cover of the
SquareFold Trimmer D1 to open the cover.
2 Remove the jammed paper.
3 Close the cover.
Long Paper Jam
If you open the cover of printer unit while printing a long paper, the paper will remain in the
paper feeding unit and you cannot remove the paper.
In this case, remove the paper with the following steps.
1 Close the cover of printer unit.
2 Wait until the paper is passed to the Transfer Module.
z
When the paper is transferred, a message in the Error Message area will change.
3 Pull the Transfer Module out, and then remove the paper remained in the area, "2a" or "2c".
z
While pulling the Transfer Module out, stop when the jammed paper is visible, and then continue to pull it out
with the paper holding down by a hand.
When Optional Units are Installed
If the jammed paper is lying across more than one unit, open the levers of units on both
sides that are indicated in the Error Message area before you remove the jammed paper.
To Next Page
