Stapler Faults
237
6 Hold the handle of the booklet staple cartridge, and push it in.
Fit the booklet staple cartridge ( ) to the booklet maker unit ( ).
7 Slowly push the booklet maker unit [3] all the way into the device.
8 Close the door.
z
A message will be displayed and the device will not operate if the finisher front door is even slightly open.
If the staples cannot be removed after carrying out the above procedures, contact our
Customer Support Center.
Re-inserting the Staple Cartridge into the Cartridge Unit
The following describes how to re-insert the staple cartridge to the unit when it has been
fallen off from its unit accidentally when the Finisher D6 with Booklet Maker (optional) is
installed.
z
The procedure is the same as when the staple cartridge is removed from the unit.
1 Open the cover of the unit as shown in the figure, and remove the jammed staple.
