63 Network Basics
Printing and Checking the Printer Settings Page
Print the Printer Settings page and check your printer's IP address.
This section includes:
• "The Operator Panel" on page 63
• "The Printer Setting Utility" on page 63
The Operator Panel
1 Press the (Menu) button.
2 Select Information Pgs, and then press the button.
3 Select Printer Settings, and then press the button.
The Printer Settings page is printed.
4 Confirm the IP address next to IP Address under Network Setup on the Printer Settings page. If
the IP address is 0.0.0.0, wait for a few minutes to resolve the IP address automatically, and then
print the Printer Settings page again.
If the IP address is not resolved automatically, see "Assigning an IP Address (for IPv4 Mode)" on
page 59.
The Printer Setting Utility
The following procedure uses Windows XP as an example.
1 Click start → All Programs → Fuji Xerox → Fuji Xerox Printer Software for Asia-Pacific →
FX DocuPrint CP205/FX DocuPrint CP205 w
→ Printer Setting Utility.
NOTE:
• The Select Printer window appears in this step, when multiple print drivers are installed on your
computer. In this case, click the name of the desired printer listed in Printer Name.
The Printer Setting Utility appears.
2 Click the Printer Settings Report tab.
3 Select Information Pages from the list at the left side of the page.
The Information Pages page is displayed.
4 Click the Printer Settings button.
The Printer Settings page is printed.
If the IP address is 0.0.0.0 (the factory default) or 169.254.xx.xx, an IP address has not been
assigned.
See also:
• "Assigning an IP Address (for IPv4 Mode)" on page 59
