Trouble shooting 7 E14. 3
INDOOR UNIT Error Method:
Indoor unit Network communication
Error
Indicate or Display:
Indoor Unit : Operation LED 1 times Flash, Timer LED 4 Times Flash,
Filter LED Continuous Flash.
Outdoor Unit : E.1 4. 1 / 1 4. 2 *
Error Code : 1 4 / 1 6 / 9 U / 14.1 / 14.2 / 14.3 *
Detective Actuators:
Indoor unit Controller PCB circuit
Indoor unit Communication PCB
Detective details:
When the cut-off of network communication is detected (more than 90 seconds
passed since the last receipt of Outdoor unit signal).
Check Point 2 : Check the connection
After turning off the power, check and correct followings.
Is Indoor Communication PCB loose?
Check loose or removed connection of communication line Indoor unit => RB unit => Outdoor unit.
When the signal amplifier is connected , Check the error indication of signal amplifier. ( Refer to the installation manual)
Check Point 3 : Check Communication PCB
Replace Communication PCB of the Indoor units that have the error.
OK
Forecast of Cause : 1. Outside cause 2.Connection failure 3. Communication PCB failure 4. Controller PCB failure
Check the Error indication of RB unit.
Check Point 1 : Check if any outside cause such as voltage drop or noise
Instant voltage drop ----- Check if there is any electric equipment with a large load within the same circuit.
Momentary power failure ----- Check contact failure or leak current in power supply circuit
>>Check power supply for RB unit and Outdoor Unit as well.
Check if there is any equipment that causes harmonic wave near the power cable (Neon light bulb or any electronic equipment which
causes harmonic wave). And check the complete insulation of grounding.
>>If the same symptom does not reappear after resetting the power, possibility of noise is high.
Check Point 4 : Check Controller PCB
OK
If still the error is there, replace the communication PCB of the RB unit which corresponds to the error indicating Indoor unit.
Replace controller PCB of the Indoor units that have the error.
If still the error is there, replace the controller PCB of the RB unit which corresponds to the error indicating Indoor unit.
* Outdoor unit indicates 1 4.1 or 1 4.2 (No communication from 14.3 Error Indoor unit)
Peripheral device indicates 1 4 or 1 6
Refer to SERVICE INFORMATION Network communication Abnormal
Refer to SERVICE INFORMATION RB Unit Abnormal
