Fujitsu Airstage VR-II ASUB24TLAV User Manual

06-12
Cut the Discharge pipe in this range. Cut the Suction pipe in this range.
Remove the Compressor.
Caution
Keep their shape better.
There is a possibility of catching fire to oil when removing by the welding without cutting it.
Range
Range
Procedure for compressor installation.
Reverse procedure to removing the compressor.
Precautions for installation of Compressor.
(1) When brazing, do not apply the flame to the terminal.
(2) When brazing, be sure to replace the air in the pipe with nitrogen gas to prevent forming oxidization scale.
