"MODE/ EXIT" button
short press
"ENTER" button
short press
It changes if the
"SELECT" buttonis
short pressed
"ENTER" button
short press
Select the History Number Return to the Monitor Mode
example) Normal display (Cooling operation)
Change to the Error History Mode from the Mode Selection Display
Select the Error History Number
Check the detail of the Error History
00 01 02 09
Select the History Number
example) Error Code : E711
Mode selection display The newest History Number and
Error Code are displayed by the 2 digits
: Light off
: Flashing
: Lighting
The History Number changes sequentially
from "00" to "09" by the "SELECT" button
End of the Error History mode
Mode Selection Display
Monitor Mode
Select the
Error History Number
Display details
of the
Error History
ERROR HISTORY MODE
3
2
4
1
4
3
2
1
Error History Number : [00]Error Code : [71]
4-2-8 ERROR HISTORY MODE
[Forward]
[Forward]
"SELECT" button
short press
LED101
LED104
POWER
MODE
ERROR
(GREEN)
LED102
(RED)
LED105
"ENTER" button
short press
It changes if the
"SELECT" button
is short pressed
[Forward]
Error History Number : [01]
Error Code : [- -]
There is no Error History yet,
in the object History Number
(Newest)
(Oldest)
Detail of Error Code is displayed by the 3 digits
If there is no Error History,
detail of Error Code is displayed as above
When the abnormality occurred, the Outdoor unit memorizes the history of error codes up to 10
and it can be displayed on 7 segments LED.
It is an effective means to examine abnormality that occurred in the past.
*The error history can be cleared by setting to F3-30.
Refer to the following for the procedure.
