1-6 Field Setting And Monitor Mode List for Outdoor unit
Push switch on
outdoor unit PCB
[ F1 ]
Monitoring mode
ITEM
CODE No.
Information contents
Classification
00
Connected number of indoor unit
The number of the communicating unit is displayed
Device and
system
01
Software version :
[ ] [ ] [ ] [ ] [ ] displays by five items
It skips when there is no suffix
02 Software version of INV PCB
03 Software version of communication PCB
Software version of outdoor unit
Operation of
each part
10 Rotational speed of outdoor unit fan motor
The rotational speed of the outdoor unit fan motor is displayed
[ 0 ~ 999 ] rpm
11 Rotational speed of INV compressor
The rotational speed of the compressor is displayed
[ 0 ~ 999 ] rps
12 Current value of INV compressor Current value of INV compressor is displayed
14 Pulse of EEV1 Pulse of EEV1 is displayed
15 Pulse of EEV2 Pulse of EEV2 is displayed
16 Pulse of EEV3 Pulse of EEV3 is displayed
[ 0.00 ~99.99 ] A
[ 0 ~ 9999 ] pls
[ 0 ~ 9999 ] pls
[ 0 ~ 9999 ] pls
Accumulated current time is displayed
[ 0 ~ 9999 ]
10hour
Accumulated time is displayed in the cooling operation of the
INV compressor
Accumulated time is displayed in the heating operation of the
INV compressor
[ 0 ~ 9999 ]
10hour
[ 0 ~ 9999 ]
10hour
Time guard 20 Accumulated current time
21 INV compressor accumulated time [ Cooling ]
22
INV compressor accumulated time [ Heating ]
Refrigerant
cycle data 1
30 Information on Thermistor 1
31 Information on Thermistor 2
32
Information on Thermistor 3
33
Information on Thermistor 4
34 Information on Thermistor 5
35 Information on Thermistor 6
36 Information on Thermistor 7
37 Information on Thermistor 8
38 Information on Thermistor 9
39 Information on Thermistor 10
( Discharge temperature sensor 1)
( Outdoor temperature sensor )
( Suction temperature sensor )
( Liquid temperature sensor 1)
(Liquid temperature sensor 2)
( Sub-cool H-Ex (outlet) sensor )
(Heat exchanger 1 gas sensor1)
(Heat exchanger 2 gas sensor2)
(Heat exchanger 1 liquid sensor)
(Heat exchanger 2 liquid sensor)
40 Information on Thermistor 11
The value of the Thermistor 11 is displayed
50 Information on pressure sensor 1
( High pressure sensor )
Refrigerant
cycle data 3
51 Information on pressure sensor 2
( Low pressure sensor )
(Compressor temperature sensor)
Refrigerant
cycle data 2
The value of the Thermistor 1 is displayed
[ -99.9 ~ 999.9 ]
°C or °F
[ -99.9 ~ 999.9 ] °C or °F
[ -99.9 ~ 999.9 ] °C or °F
[ -99.9 ~ 999.9 ] °C or °F
[ -99.9 ~ 999.9 ] °C or °F
[ -99.9 ~ 999.9 ] °C or °F
[ -99.9 ~ 999.9 ] °C or °F
[ -99.9 ~ 999.9 ] °C or °F
[ -99.9 ~ 999.9 ] °C or °F
[ -99.9 ~ 999.9 ] °C or °F
[ -99.9 ~ 999.9 ] °C or °F
[ -99.9 ~ 999.9 ] °C or °F
[ -99.9 ~ 999.9 ] °C or °F
The value of the Thermistor 2 is displayed
The value of the Thermistor 3 is displayed
The value of the Thermistor 4 is displayed
The value of the Thermistor 5 is displayed
The value of the Thermistor 6 is displayed
The value of the Thermistor 7 is displayed
The value of the Thermistor 8 is displayed
The value of the Thermistor 9 is displayed
The value of the Thermistor 10 is displayed
The value of the pressure sensor 1 is displayed
If unit is [MPa], it is displayed as [ 0.00 ~ 9.99 ]
[psi], it is displayed as [ 0.0 ~ 999.9 ]
The value of the pressure sensor 2 is displayed
If unit is [MPa], it is displayed as [0.00 ~ 9.99]
[psi], it is displayed as [ 0.0 ~ 999.9 ]
