1. OPERATIONAL OVERVIEW
1-23
If you selected [UTC], close the menu. If you selected [LOCAL], go to step 6.
6. Select [3 ADJUST LOCAL TIME].
7. Spin the scrollwheel, or use the number keys to input the desired offset.
The offset must be in 30 minute increments.
Note: Regarding input for [3 ADJUST LOCAL TIME], when using the number
keys, the indication is first selected as a whole. At this time, you can toggle be-
tween plus “+” or minus “-”. Press the 8 key for “-”, press the 2 key for “+”. If single
digits are highlighted, toggle is not possible. In this case, press the CANCEL
TRAILS key to re-highlight the whole indication.
8. Close the menu.
1.15 User Settings
The user functions shown in the table below can be reset to their default settings by
enabling the [PILOT SETTING] option in the [USER SET] menu. Functions not shown
in the table below maintain their previous setting.
The unit can store two separate user settings, for the functions listed below, in the in-
ternal memory. These settings can also be recalled. Functions not shown in the table
below cannot be stored or recalled.
Function Setting(s) Menu/On-screen box
GAIN Maintained as per
previous setting.
[GAIN] box
SEA [AUTO] [SEA] box
RAIN [AUTO] [RAIN] box
TUNE [AUTO] [TUNE] box (Magnetron radars only)
TX CH Maintained as per previous setting. (Solid State radars only)
Range [6 NM] [RANGE] box
Range rings [OFF] [MAIN MENU] o [3 NAV TOOLS] o [4 RANGE
RINGS]
VRM1 Display [ON] [VRM1] box
Distance [0.250 NM]
VRM2 Display [OFF] [VRM2] box
Distance [0.000 NM]
EBL1 Display [ON] [EBL1] box
Bearing Maintained as per
previous setting.
Reference Maintained as per
previous setting.
[MAIN MENU] o [3 NAV TOOLS] o [3
EBL•VRM•CURSOR SET] o [5 EBL•CURSOR
BEARING]
Time indication highlighted as a whole.
Toggle between “+” and “-” is possible.
Single digit is highlighted. Toggle
between “+” and “-” is not possible.
To Next Page
