FELCOM 82
H3-7
3) Rotor voltage (between R1 and R2)
Rotor voltage SW2 #1 JP3 Remarks
20 to 45 VAC ON #2
30 to 70 VAC OFF #2
40 to 90 VAC ON #1
60 to 135 VAC OFF #1
4) Stator voltage (between S1 and S2)
Stator voltage SW2 #2 SW2 #3 JP3 Remarks
20 to 45 VAC
20 to 60 VDC
ON OFF #2
30 to 70 VAC
40 to 100 VDC
OFF OFF #2
40 to 90 VAC ON OFF #1
60 to 135 VAC OFF OFF #1
5) Ratio
Ratio SW1 #1 SW1 #2 SW1 #3 Remarks
360x OFF OFF OFF
180x ON OFF OFF
90x OFF ON OFF
36x ON ON OFF
6) Supply voltage
Supply voltage JP4 JP5 Remarks
20 to 45 VAC
20 to 60 VDC
#2 #2
30 to 135 VAC
40 to 100 VDC
#1 #1
7) NMEA data output interval
SW2, #4 selects the output interval either 2 sec. or 1 sec.; ON: 2 sec. and OFF: 1 sec.
8) AD10 data output interval
Select to 25 ms by changing the jumper block on JP6 and JP7 corresponding to
the output port. Do not use 200 ms.
