A QUICK GUIDE: GETTING STARTED WITH A
BASIC
4-CHANNEL AIRCRAFT
This guide is intended to help you get acquainted with the radio, to give you a jump start on using your new radio, and to
give you some ideas and direction on how to do even more than you may have already considered. It follows our basic
format of all programming pages: a big picture overview of what we accomplish; a “by name” description of what we're
doing to help acquaint you with the radio; then a step-by-step instruction to leave out the mystery when setting up your
model.
For additional details on each function, see that function's section in this manual. The page numbers are indicated in the
goals column as a convenience to you.
See p.26 for a legend of symbols used.
GOALS of EXAMPLE STEPS INPUTS for EXAMPLE
Prepare your aircraft. Install all servos, switches, receivers, etc. per your model's instructions. Turn
on transmitter then receiver; adjust all linkages so surfaces are nearly centered.
Mechanically adjust all linkages as close as possible to proper control throws.
Check servo direction. Make notes now of what you will need to change during
programming.
Name the model.
P. 32.
[Note that you do not need to do
anything to "save” or store this data.
Only critical changes such as a
MODEL
RESET
require additional keystrokes to
accept the change.]
Open the
BASIC
menu, then open the
MODEL
submenu.
Turn on the transmitter.
for 1 second.
(If
ADVANCE
, again.)
C
as needed to highlight
MODEL
.
to choose
MODEL
.
Go to
MODEL NAME
.
C
to
NAME
.
(First character of model's name is
highlighted.)
Input aircraft's name.
Close the
MODEL
submenu.
WRFKDQJH¿UVWFKDUDFWHU
When proper character is displayed,
C
to move to next character.
Repeat as needed.
to return to
BASIC
menu.
Reverse servos as needed for proper
control operation.
P. 38.
In the
BASIC
menu, open (servo)
REVERSE
.
C
to
REVERSE
.
to choose
REVERSE
.
Choose desired servo and reverse its
direction of travel. (Ex: reversing rudder
servo.)
C
to
CH4: RUDD
.
so
REV
is highlighted.
Repeat as needed.
Adjust Travels as needed to match
model's recommended throws (usually
listed as high rates).
P. 39.
From
BASIC
menu, choose
END POINT
.
C
to
END POINT
.
to choose
END POINT
.
Adjust the servo's end points.
(Ex: throttle servo)
Close the function.
C
to
THROTTLE
.
THROTTLE STICK.
until carb barrel closes as desired.
THROTTLE STICK.
until throttle arm just opens carb
fully at full THROTTLE STICK.
Repeat for each channel as needed.
