GETTING STARTED WITH A BASIC 4-CHANNEL (Aileron/Flap/Rudder/Elevator) GLIDER
This guideline is intended to help you get acquainted with the radio, to give you a jump start on using your new radio,
and to give you some ideas and direction in how to do even more with this powerful system than you may have already
considered. It follows our basic format of all programming pages: a big picture overview of what we’re trying to
accomplish; a “by name” description of the steps to help acquaint you with the radio; and a step-by-step instruction to
leave out the mystery and challenge of setting up your model.
For additional details on utilizing each function, see that function’s section in this manual—the page numbers are indicated
LQWKH¿UVWFROXPQDVDFRQYHQLHQFHWR\RX
GOAL of EXAMPLE: STEPS: INPUTS:
Prepare your aircraft. Install all servos, switches, receiver per your model’s instructions. Turn on
transmitter then receiver; adjust all linkages so surfaces are nearly centered.
Mechanically adjust all linkages to get as close as possible to proper control
throws and minimize binding prior to radio set up.
Check servo direction and throws.
Make notes now of what you will need to change during programming.
Select the proper
MODEL TYPE
for your
model. (Ex:
GLID 1A+1F
.) See p. 78.
[NOTE: This is one of several functions
that requires confirmation to make a
change. Only critical changes such as
a
MODEL RESET
require additional key
strokes to accept the change.]
In the
BASIC
menu, open the
PARAMETER
submenu.
Turn on the transmitter.
for 1 second.
(If
ADVANCE
, again.)
then
C
to highlight
PARAMETER
.
to choose
PARAMETER
.
Go to
MODEL TYPE
.
C
to
MODEL TYPE
.
Select proper
MODEL TYPE
.
Ex:
GLID(1A+1F)
.
&RQ¿UPWKHFKDQJH
Close the
PARAMETER
submenu.
to
GLID(1A+1F)
.
for 1 second.
Are you sure?
Displays.
WRFRQ¿UP
to return to
BASIC
menu.
NAME
the model.
P. 32.
(Note that you do not need to do
anything to "save" or store this data.)
In the
BASIC
menu, open the
MODEL
submenu.
C
as needed to highlight
MODEL
.
to choose
MODEL
.
Go to
MODEL NAME
.
C
to
NAME
.
(1
st
character of model’s name is highlighted.)
Input aircraft’s name.
Close the
MODEL
submenu when done.
WRFKDQJH¿UVWFKDUDFWHU
When proper character is displayed,
C
to move to next character and
repeat.
to return to
BASIC
menu.
REVERSE
servos as needed for proper
control operation.
P. 38.
In the
BASIC
menu, open (servo)
REVERSE
.
C
to
REVERSE
.
to choose
REVERSE
.
Choose desired servo and reverse its
direction of travel.
(Ex: reverse rudder servo.)
C
to
CH4:RUDD
.
so
REV
is highlighted.
Are you sure?
Displays.
for 1 second.
Repeat as needed.
to return to
BASIC
menu.
