55
Using Twin Aileron Servos,
AILE-2
(
ACRO

GLID
):
AILE-2
only tells the radio that you are using CH5 and CH6 (
FLAPERON
), or CH5
and CH7 (
AIL-DIFF
), not CH6 or CH7, as the second servo in
FLAPERON
or
AILE-
DIFF
. You still must activate and set up the
FLAPERON

AILE-DIFF
function.
Note that selecting
CH6&5
or
CH7&5
does NOT free up CH6 or CH7 to be used for other functions when using a receiver
with more than 5 channels. Both 5 and 6 (
FLAPERON

AILE-DIFF
) are dedicated to the
FLAPERON
or
AILE-DIFF
programming.
>7KLVLVEHQH¿FLDOZLWKIRXUDLOHURQVHUYRVWKDWQHHGWRKDYHWKHLUHQGSRLQWVRUVXEWULPVVHWVHSDUDWHO\&+&+DQG
CH6 are already fully set up to operate as ailerons. Mix CH7 or CH8 (the second aileron servo on the other side) into
ailerons to function properly.]
GOAL of EXAMPLE: STEPS: INPUTS:
Adjust the second aileron servo output
from
CH6or7
to channels
CH6&5
.
Allows twin aileron servo operation
with a 5-channel receiver.
Open the
PARAMETER
submenu.
for 1 second.
(If
ADVANCE
, again.)
C
to
PARAMETER
.
Select
AILE-2
and change to
CH6&5
.
C
to
AILE-2
. to
CH6&5
.
Close menu.
Where next? Finish setting up
FLAPERON
or
AILE-DIFF
. see Twin Aileron Servos: p. 51.
View additional model setups on the internet: www.futaba-rc.com\faq\
