FUTABA 10CAG User Manual

83
SPOILER MIX
(
GLID
PRYHVWKHVSRLOHUVE\ÀLSSLQJWKHDVVLJQHGVZLWFKDQGLVXVHGWRPDNHVWHHSGHVFHQWV$QG
SPOILER
MIX
works linking with
BUTTERFLY
function.
Adjustability:
•
Position: -100% to +100%, with a default of -50% (off), +50% (on)
•
Channel: Spoiler 1: ch8, 5 or 3 (ch8 or 3*), Spoiler 2: NULL, ch5 or 3 (NULL or ch3*)
*
GLID (2A+2F)
mode
• Elevator setting: Rate: -100% to +100%, Delay: 0% to 100%
•
SWITCH A-H fully assignable. Also LOGIC SW (Lsw1 to 3) may be assigned. Set up
LOGIC SW
: See p. 38.
GOAL of EXAMPLE: STEPS: INPUTS:
2-servo spoiler mode.
Adjust the spoiler servo position to
60%
.
Open the
SPOILER MIX
function and
move to 2nd page.
for 1 second. (If
BASIC
, again.)
C
to
SPOILER MIX
.
to 2nd page.
Activate the function.
C
to
MIX
. to
ON
.
Assign the
SPO2-CH
. (Ex: CH3)
C
to
SPO2-CH
. to
CH3
.
Adjust the spoiler servo position.
(Ex:
SPO1

SPO2
=
+55%
to
+60%
)
C
to
+50%
. (
SPO1
) to
+60%
.
C
to
+50%
. (
SPO2
) to
+60%
.
Optional: Set the elevator rate.
(EX:
10%
)
C
to
rate
-
ELE
. to
10%
.
Optional: Set the delay. (EX:
25%
)
C
to
dly
-
ELE
. to
25%
.
Close menu.
Where next? Set up
BUTTERFLY
mixing: see p. 87.
