85
Camber Mixing (
CAMBER MIX
)(
GLID
):
This function adjusts the mixing rate of camber operation which operates the
ZLQJ FDPEHU DLOHURQV DQG ÀDSV LQ WKH QHJDWLYH DQG SRVLWLYH GLUHFWLRQV7KH
DLOHURQÀDSDQGHOHYDWRUUDWHVFDQDOVREHDGMXVWHGLQGHSHQGHQWO\DQGDWWLWXGH
changes caused by camber operation can be corrected.
Also the operation reference point of camber control can be offset. (
PRE
)
NOTE: Camber control is not assigned at default.
GOAL of EXAMPLE: STEPS: INPUTS:
Ex: Set the mixing amount for aileron
to
40
%, camber control to VR(E),
reference point to desired point.
Open the
CAMBER MIX
function.
for 1 second.
(If
BASIC
, again.)
C
to
CAMBER MIX
.
Choose desired slider.
C
to
VR
. to VR(E).
Adjust the mixing amount for
AILE
.
(Ex: adjust to
40%
.)
C
to
AILE
. VR(E). to
40%
.
VR(E). to
40%
.
Set the reference point.
C
to
PRE
. or VR(E) to
desired point.
for one second.
Close menu.
Adjustability:
•
Rate: -100% to +100%, with a default of +30%
•
Reference point (
PRE
): The operation reference point of camber control can be offset. -100% to +100%, with a default of 0%.
START DELAY
(
GLID 1A+1F
only):
START DELAY
automatically switches the offset trims (
OFFSET
) from the
START
condition's trims to the normal condition's trims after the delay time (max.10sec.).
This delay time set by the
-dly-
item when activating the
START
condition. (It is
convenient for hand launch glider.)
NOTE: The same delay amount for elevator and rudder is recommended when
using V-tail function.
Adjustability:
• Delay time (
-dly-
) range of 0 to 100%. The delay time is 10 second at 100%.
GOAL of EXAMPLE: STEPS: INPUTS:
Ex: delay time=5 second. Open
ADVANCE
menu, then open
START
DELAY
function.
for 1 second.
(If
ADVANCE
, again.)
C
to
START DELAY
.
Activate the function.
C
to
MIX
. to
OFF
or
ON
.
Set the delay time.
(Ex:
50%
each surface)
C
to
ELEV
. to
5O%
.
C
to
RUDD
. to
5O%
.
Repeat as needed.
Close.
