Installation Materials
190-01810-00 GDL 82 TSO Installation Manual
Rev. 5 Page 3-3
3.2 Optional Accessories
Table 3-5 Optional Accessories
• Ligh
t, indicator, press-to-test, small, MS25041-4
• Lamp,
T-1 3/4, midget flange, MS25237-330
• Ligh
t, indicator, press-to-test, small, MS25041-4
• Lamp,
T-1 3/4, midget flange, MS25237-327
Vendor Contact Information (provided for convenience only):
Amphenol RF, Four Old Newtown Road, Danbury, CT 06810 Phone: (800) 627-7100
www.amphenol.com
3.3 Materials Required but not Supplied
The GDL 82 is intended for use with standard aviation accessories. The following items are required for installation, but
not supplied.
If using MIL-W-22759/18, support and protect the wire.
1. Wire (MIL-W-22759/16 or equivalent)
2. Shielded wire (MIL-C-27500 or equivalent)
3. Mounting screws
4. Push/pull (manually resettable) circuit breaker
5. Tie wraps or lacing cord
6. Ring terminals (for grounding)
7. Coaxial cable (RG-400, RG-142B, or equivalent) and connectors
8. USB-A to USB-B cable (for interface between the computer USB-A receptacle and the GDL 82 USB-B receptacle)
ITEM GARMIN P/N MFG P/N
Annunciator, 14VDC N/A
Annunciator, 28VDC N/A
Connector, BNC, Male, Clamp 330-00087-00 N/A
Connector,
TNC, Male, Clamp N/A Amphenol: 031-4452 Not available from Garmin.
GPS 1.57542 GHz Notch Filter 330-00067-00 N/A
