Garmin GDL 82 User Manual

System Configuration
190-01810-00 GDL 82 TSO Installation Manual
Rev. 5 Page 7-11
Squat Switch
This input determines the aircraft on-ground status.
Table 7-2 Squat Switch Selections
7.3.2 Transponder
The code must match the VFR code configured on the transponder. This is typically 1200 for U.S. registered aircraft.
This setting is used for the UAT anonymous mode feature (if enabled). The transponder must be tuned to this code
before the GDL 82 is capable of transmitting a temporary address and a flight ID. This field has a range of
0000-7777 (octal).
7.3.3 GPS
Source
Enter the GPS source for the GDL 82.
Table 7-3 GPS Source
Longitudinal Antenna Offset
Enter the offset distance (in feet) of the GPS antenna from the aircraft nose to the center of the GPS antenna.
SELECTION DESCRIPTION
Not Installed No squat switch installed in aircraft.
GND (0V) = On Ground Switch must be grounded to indicate aircraft is on ground.
GND (0V) = Airborne Switch must be grounded to indicate aircraft is airborne.
SOURCE DESCRIPTION
Internal GLD 82 with Internal GPS/SBAS
GNS Series GNS 4XXW/5XXW Series Navigators
ADS-B+ Format 2 GTN 6XX/7XX or GNS 480

Garmin GDL 82 Specifications

General

Brand	Garmin
Model	GDL 82
Category	Transceiver
Language	English
