Garmin GDL 82 - Special Tools

Installation Materials
190-01810-00 GDL 82 TSO Installation Manual
Rev. 5 Page 3-4
3.4 Special Tools
The following special tools are required for building the harness.
3.4.1 Milliohm Meter
A milliohm meter with an accuracy of +0.1 milliohm (or better) to perform continuity and power/ground checks.
3.4.2 Crimp Tool
A crimp tool meeting MIL specification M22520/2-01 and a positioner/locator are required to ensure consistent,
reliable crimp contact connections for the D-Sub connector. D-sub insertion/extraction tools from ITT Cannon are all
plastic, others are plastic with metal tip.
Table 3-6 Recommended Crimp Tools
3.4.3 Test Equipment
The following equipment is required for the pre and post installation checks.
• Ground power source (capable of powering all aircraft systems)
• Transponder ramp test set (e.g., Aeorflex IFR-6000 or TIC TR-220)
• ADS-B test set (e.g., Garmin GDL 39 and Garmin Pilot application) if a transponder ramp test set is not capable
of receiving UAT (978 MHz) ADS-B Out messages
MANUFACTURER
HAND
CRIMPING TOOL
22 – 28 AWG (P821)
POSITIONER
INSERTION/
EXTRACTION TOOL
Military P/N M22520/2-01 M22520/2-09
M81969/14-01
M81969/1-04
Positronic 9507-0-0-0 9502-4-0-0 M81969/1-04
ITT Cannon 995-0001-582 995-0001-739
000829490
274-7048-000MIL
AMP 601966-1 601966-6
91067-1
2031838-1
Daniels AFM8 K42
M81969/14-01
M81969/1-04
Astro 615717 615725
M81969/14-01
M81969/1-04
